XRF Coating Measurement


XRF Coating Measurement


Specifically designed for application of XRF coating thickness measurement, with excellent X-ray throughput stability and suitable for continuous operation. Through precise control on 100um focal spot size and position, it distinguishes itself from similar products of other brands.


KYW1600X

KYW1600X

Max Anode Voltage50kVBe Window Thickness200μm (100μm options available)
Anode Current0-1mAAnode MaterialW,Mo,Rh,Ag (Other materials available)
Max Power50WCooling MethodForced air @ 150 CFM
Focal Spot Size100μmMax Package Temperature55℃
Nominal Filament Voltage2.5V@50kV,1mA Grounding MethodGrounded Cathode
Filament Current1.5ADimensionФ70x185.5
Cone  Angle20°Approximate Weight2.9kg



Consult Now

KYW900 Brass Housing Tube Series

KYW900 Brass Housing Tube Series

Max Anode Voltage50kVBe Window Thickness200μm (100μm options available)
Anode Current0-1mAAnode MaterialW,Mo,Rh,Ag(Other materials available)
Max Power50WCooling MethodForced air @ 150 CFM
Focal Spot Size1mm(100μm options available)Max Package Temperature55℃
Nominal Filament Voltage2 .5V@50kV,1mAGrounding MethodGrounded Cathode
Filament Current1.7ADimensionФ90x223
Cone  Angle20°Approximate Weight5.6kg



Consult Now

KYW5000 Tube Replacement Series

KYW5000 Tube Replacement Series

Max Anode Voltage50kVBe Window Thickness100μm(200μm options available)
Anode Current0-1mAAnode MaterialW, Mo (Other materials available
Max Power50WCooling MethodForced air @ 150 CFM
Focal Spot Size100μm ★Max Package Temperature55℃
Nominal Filament Voltage2.0@50kV,1mA Grounding MethodGrounded Cathode
Filament Current1.7ADimensionФ70x163.5
Cone  Angle20°Approximate Weight2kg



Consult Now
